Half Moon Spanner

Half Moon Spanner

Product Overview

HALF MOON SPANNERS



PRODUCT NO.
SIZE
B1
LA1Weight grams
HM 0810
8X10
16.0
1256.0
455
HM 1011
10X11
19.0
1357.0
600
HM 1213
12X13
21.0
1508.0
800
HM 1415
14X15

22.5

1709.5
1150
HM 1617
16X17
25.518510.5
1400
HM 1819
18X19
28.520011.0
1800
HM 2022
20X22
32.022013.0
1300


Special Features


Salient Features

  • Drop forged from high grade Chrome- Vanadium steel.
  • Scientifically heat treated to give maximum strength and wear resistance.
  • Slightly rounded shank -sand blasted –fit snugly in the hand and gives comfortable grip.
  • Good accessibility in confined spaces due to slim and practical design.
  • Clearly marked –facilitates choice of right size.
  • Thoroughly corrosion protected with Nickel-Chrome finish.
  • Available in different sizes.i.e A/F 8 To A/F 22 mm.
  • Minimum Torque Value in Kg.m:



Nominal Size A/F
Torque Value in Kg.m
83.5
105.9
117.4
129.1
1310.9
1413.1
1515.3
1617.8
1720.5
1823.5
1926.6
2030
2237.5
