FLAT HEAD BITS.
| PRODUCT NO. | L | B | C | A | Weight grames |
| SBF 253 | 25 | 3 | 15 | 0.50 | 4.5 |
| SBF 254 | 25 | 4 | 15 | 0.60 | 4.5 |
| SBF 255 | 25 | 5 | 15 | 0.80 | 4.5 |
| SBF 256 | 25 | 6 | 15 | 1.00 | 5.0 |
| SBF 258 | 25 | 8 | 15 | 1.20 | 5.0 |
| SBF 503 | 50 | 3 | 25 | 0.50 | 8.5 |
| SBF 504 | 50 | 4 | 25 | 0.60 | 8.5 |
| SBF 505 | 50 | 5 | 25 | 0.80 | 10.0 |
| SBF 506 | 50 | 6 | 25 | 1.00 | 11.0 |
| SBF 508 | 50 | 8 | 25 | 1.20 | 11.0 |
TAPARIA Bits are made from special grade Alloy Steel.
Scientifically heat-treated to give maximum strength & wear resistance.
TAPARIA Bits are 30% higher wear resistance and torque as compared to Bits made from Cr-V steel.
The tip is precision – machined to ensure firm grip in the screw slot.
Bits are effectively protected against corrosion by special coating and rust prevention oil.
Available in 1/4 Hexagonal drive in 25 mm, 50 mm, 65 mm & 110 mm lengths.
Available in different tip profile :
A] Flat: 3 x 0.5, 4 x 0.6, 5 x 0.8, 6 x 1.0 & 8 x 1.2 mm
B] Hexagon :
Metric series A/F -1.5, 2, 2.5, 3, 4, 5, 6, 8, 10 mm.
Inch Series A/F - 1/16, 5/64, 3/32,7/64,1/8,9/64, 5/32, 3/16, 7/32 & 1/4.
C] Philips: 0, 1, 2 & 3
D] Torx: T5, T6, T7, T8, T9, T10, T15, T20, T25, T27, T30, T40, T45.
E] Double Headed: PH1xPH1, PH1xPH2, PH1xPH3, PH2xPH2, PH2xPH3 & PH3xPH3.
F] Two in One SD Bits:PH2x SL6mm, PH1 x SL4.5mm, PH2x SL5.5mm &PH3x SL6.5mm,
G] Pozi Drive : PZ1, PZ2
